0 to 100% Horizontal Dry Bulb Economizer
Click the e-library symbol for the latest version
| Model Number: | Used With: |
| FIAECON303* | T/YS*180-300, W/D/GS*150-300 |
Introduction
Read this manual thoroughly before operating or servicing this unit. See below to download a PDF of the 0 to 100% Horizontal Dry Bulb Economizer Guide.
Note 1:
How to configure the Symbio 700 for economizer accessory:
Settings > View Configuration > Edit > Stopping the Equipment (Proceed) > Outside Air
Change:
Outside Air - 0 to 100% Economizer
Remote Minimum Position- Not Installed
Economizer Type - Dry Bulb, Reference Enthalpy, Differential Dry Bulb, Comparative Enthalpy
Note 2:
For power exhaust accessories click the link below
https://support.trane.com/hc/en-us/articles/12206337173389-Power-Exhaust-Precedent-6-to-25-Tons
WARNING:
Information in this article is intended for use by individuals possessing adequate backgrounds of electrical and mechanical experience and who comply with all federal, state, and local laws, rules, orders, or regulations related to the installation, service, or repair of a heating or central air conditioning product. Any attempt to install, service, or repair a heating or central air conditioning product may result in personal injury and/or property damage. The manufacturer or seller cannot be responsible for the interpretation of the information contained herein, nor can it assume any liability in connection with its use.
